LAN/WLAN communication module
Power supply: 3.3VDC,
Current consumption: min.500mA,
Operating temperature range: -40 … + 85 ° C
CAI_LanWlan-SOC-IA-01
€86,00 excl. VAT, excl. shipping
| Quantity | Discount | Price |
|---|---|---|
| 1 - 4 | — | €86,00 |
| 5 - 9 | 11 % | €76,54 |
| 10 - 49 | 17 % | €71,38 |
| 50 - 99 | 23 % | €66,22 |
| 100 - 249 | 32 % | €58,48 |
| 250 - 499 | 35 % | €55,90 |
| 500+ | 39 % | €52,46 |
Beschreibung
With this module, a corresponding IMACS host board (e.g. CPU board) can be expanded to include a WLAN interface and an Ethernet connection, thus establishing a data connection with other systems such as a visualization PC.
The module firmware determines in which operating mode the module is operated, i.e. whether it functions as a transparent network interface for WLAN and Ethernet or only as a bridge for RS232.
The ESP32-wroom-32D product from Espressif Systems is used here.
See also:
https://www.espressif.com/sites/default/files/documentation/esp32-wroom-32d_esp32-wroom-32u_datasheet_en.pdf
The speed of the Ethernet interface is internally limited to about 512Kbit/s, even if it is externally signaled as 10 Mbit/s.
Technical specifications
More information upon request
