I/O Brick_General-Purpose:
6x Analog-Input, 10V, 2/3-wire
2x Temperature, PT1000, 2-wire, 0..50°C
CAE_G-6Ai2Tmp-02
€66,00 excl. VAT, excl. shipping
| Quantity | Discount | Price |
|---|---|---|
| 1 - 4 | — | €66,00 |
| 5 - 9 | 11 % | €58,74 |
| 10 - 49 | 17 % | €54,78 |
| 50 - 99 | 23 % | €50,82 |
| 100 - 249 | 32 % | €44,88 |
| 250 - 499 | 35 % | €42,90 |
| 500+ | 39 % | €40,26 |
Beschreibung
ID: 2-421
Order No.: CAE_G-6Ai2Tmp-02 (-p)
Terminal: push-in (for < 0.5mm²)
Size: 4 eU (44mm x 72mm)
BBFCP: 1-1-1
Weight: 30g
The module includes six voltage (0..10V) inputs and two temperature inputs for a PT1000 with a range from 0°C up to 50°C.
For each input/sensor double terminals (ground, input) are available. An additional connected terminal field can be used for power supply distribution to the sensors. Therefore a direct connection of the sensors without separate clamps is available.
Other temperature ranges / sensors on request.
Technical specifications
Features:
| Category | Feature | Quant. | Details |
|---|---|---|---|
| Input | Analog input | 6 | 0V-10V, 2/3-wire |
| Input | Temperature | 2 | PT1000, 0°C – 50°C |
Downloads
Documents:
3D-View
More information upon request
