I/O Brick_General-Purpose:
5x Analog-Input, 0/4..20mA, 2/3-Wire
3x Pulse-Input, n-switching, 2/3-wire
CAE_G-5Ai3Imp-03
€61,00 excl. VAT, excl. shipping
| Quantity | Discount | Price |
|---|---|---|
| 1 - 4 | — | €61,00 |
| 5 - 9 | 11 % | €54,29 |
| 10 - 49 | 17 % | €50,63 |
| 50 - 99 | 23 % | €46,97 |
| 100 - 249 | 32 % | €41,48 |
| 250 - 499 | 35 % | €39,65 |
| 500+ | 39 % | €37,21 |
Beschreibung
ID: 2-453
Order No.: CAE_G-5Ai3Imp-03 (-p)
Terminal: push-in (for ≤ 0.5mm²)
Size: 4 eU (44mm x 72mm)
BBFCP: 1-1-1
Weight: 30g
This module includes 5 current (0/4..20mA) inputs and 3 n-switching pulse inputs.
The pulse inputs always measure the high time of the signal and frequencies up to 500Hz.
Technical specifications
Features:
| Category | Feature | Quant. | Details |
|---|---|---|---|
| Input | Analog input | 5 | 0/4 … 20mA, 2/3-wire |
| Input | Pulse Input | 3 | for external low side contact |
Downloads
Documents:
3D-View
