I/O Brick_General-Purpose:
4x Analog-Input, 0/4..20mA, 2/3-wire
4x Temperature, KTY2k, 2-wire, -10..50°C
CAE_G-4Ai4Tmp-01
€51,00 excl. VAT, excl. shipping
| Quantity | Discount | Price |
|---|---|---|
| 1 - 4 | — | €51,00 |
| 5 - 9 | 11 % | €45,39 |
| 10 - 49 | 17 % | €42,33 |
| 50 - 99 | 23 % | €39,27 |
| 100 - 249 | 32 % | €34,68 |
| 250 - 499 | 35 % | €33,15 |
| 500+ | 39 % | €31,11 |
Beschreibung
ID: 2-431
Order No.: CAE_G-4Ai4Tmp-01 (-p)
Terminal: push-in (for < 0.5mm²)
Size: 4 eU (44mm x 72mm)
BBFCP: 1-1-1
Weight: 30g
The module includes four current (0/4..20mA) inputs and four temperature inputs for a KTY2k with a range from -10°C up to 50°C.
For each analog input a terminal with separate ground and +24V (from the bus for sensor supply) is available. Aditionally for the temperature inputs a separate ground for a shield is supported.
Note:
The module provides a separate analog ground. The shield can be connected to the bus ground via connecting the two terminals (if sufficient) or can be connected to the earth in your system (recommended).
Technical specifications
Features:
| Category | Feature | Quant. | Details |
|---|---|---|---|
| Input | Analog input | 4 | 0/4 … 20mA, 2/3-wire |
| Input | Temperature | 4 | Temperature input, KTY81-2k, -10…50°C |
Downloads
Documents:
3D-View
More information upon request
